DXE4500-R2/51
Type: DXE4500-R2/51 Aperture:φ120mm Range: ±4500A Accuracy: 0.01% Linearity: 50ppm Bandwidth: 100KHz
Flux-gate current sensor R series
Read MoreDXE4500-R2/51
DXE4500-R1/52
Type: DXE4500-R1/52 Aperture:φ160mm Range: ±4500A Accuracy: 0.02% Linearity: 50ppm Bandwidth: 100KHz
DXE2000-R3/51
Type: DXE2000-R3/51 Aperture:φ60mm Range: ±2000A Accuracy: 0.01% Linearity: 50ppm Bandwidth: 100KHz
DXE1000-R5-G
Type: DXE1000-R5-G Range: ±1500A Working voltage: ±15~±24VDC Accuracy: 0.02% Output: 200mA Linearity:100ppm Bandwidth:DC~100KHz Aperture:about φ39.5mm
DXE500-R6-G
Type: DXE500-R6-G Range: ±750A Working voltage: ±15~±18VDC Accuracy: 0.02% Output: 200mA Linearity:100ppm Bandwidth:DC~150KHz Aperture:φ35mm
DXE500-R5-G
Type: DXE500-R5-G Range: ±750A Working voltage: ±15~±24VDC Accuracy: 0.02% Output: 100mA Linearity:100ppm Bandwidth:DC~100KHz Aperture:about φ39.5mm
DXE200-R7/55
Type: DXE200-R7/55 Range: ±240A Working voltage: ±11~±16V Accuracy: 0.05% Output: ±100mA Linearity:100ppm Bandwidth: 100KHz Measuring…
DXE200-R6-G
Type: DXE200-R6-G Range: ±300A Working voltage: ±15~±18VDC Accuracy: 0.02% Output: 100mA Linearity:100ppm Bandwidth:DC~150KHz Aperture:φ35mm
