DXD-S1-600A2000VE1

Type: DXD-S1-600A2000VE1

The DXD-S1-600A2000VE1 digital meter is a high-precision DC tester. This product adopts a brand new software and hardware design, which can simultaneously measure DC voltage, current, power, etc. It can be widely used in metrology research institutes, power, metrology, military industry, manufacturing, scientific research and other fields for DC measurement, as well as other metrology fields for DC voltmeters, ammeters, power meters, etc

DC voltage measurement DCV: 2000V

DC current measurement DCI: 600A

DC current measurement limit: 600A

DC current measurement range: (0~110%)RG

DC current measurement accuracy:  0.0005%FS+0.01%RD(0A≤I≤30A)

                                0.01%RD(30A≤I≤150A)

                                0.01%RD(150A≤I≤600A)

DC current measurement resolution: 0.0005%FS(0A≤I≤600A)

DC voltage measurement limit: 2000V

DC voltage measurement range: (0~110%)RG

DC current measurement accuracy:  ±0.01%RD(40V≤U≤2000V)

                                ±0.01%RD±4mV(0V≤U≤40V)

DC voltage measurement resolution: 0.001%RD(4V≤U≤2000V)

DC power measurement accuracy: ±0.02%RD(40V≤U≤2000V, 30A≤I≤600A)

Working voltage：AC170V～260V, 50/60Hz

Power consumption：＜30W

Warm-up time: ≤30min

Operation temperature: 10℃~35℃

Relative humidity: ≤ 85%, no corrosive gas

Weight: 4kgs
